Specification summary:
- 5 Line business Class IP phone
- Speakerphone Caller ID, call hold, conferencing and more
- Easy setup with Alliance Phones
- Monochrome backlit display for ease of use, aesthetics, and on-screen applications
- HD Voice*
- Bluetooth and Wireless-G (802.11g)
- USB 2.0 host port for charging mobile devices.
Features
- Telephony Features
- Five voice lines
- Line status: active line indication, name and number
- Menu-driven user interface
- Speakerphone
- Call hold
- Call waiting
- Caller ID name and number
- Outbound caller ID blocking
- Call transfer: attended and blind
- Three-way call conferencing with local mixing
- Multiparty conferencing via external conference bridge
- Automatic redial of last calling and last called numbers
- On-hook dialing
- Call swap
- Call blocking: anonymous and selective
- Call forwarding: unconditional, no answer, and on busy
- Call logs (60 entries each): made, answered, and missed calls
- Redial from call logs
- Personal directory with auto-dial (100 entries)
- Do not disturb
- Digits dialed with number auto-completion
- Anonymous caller blocking
- On-hook default audio configuration (speakerphone and headset)
- Multiple ring tones with selectable ring tone per line
- Called number with directory name matching
- Ability to call number using name: directory matching or via caller ID
- Subsequent incoming calls show calling name and number
- Date and time with support for intelligent daylight savings
- Call duration and start time stored in call logs
- Call timer
- Speed dialing
Applications
- Customizable screen saver on phone
- Music player (MP3)
- RSS web services
- Cisco MonitorView
Hardware Features
- Up to 5 line keys for up to 5 simultaneous calls
- Color 3.2 in QVGA (320 x 240 pixels) backlit
- Dedicated illuminated buttons for:
- Audio mute on/off
- Headset on/off
- Speakerphone on/off
- Four-way rocking directional knob for menu navigation
- Voicemail message waiting indicator light
- Voicemail message retrieval button
- Dedicated hold button
- Settings button for access to feature, setup, and configuration menus
- Volume control rocking up/down knob controls handset, headset, speaker, ringer
- Standard 12-button dialing pad
- High-quality handset and cradle
- Built-in high-quality microphone and speaker
- Headset jack: 2.5 mm
- LED test function
- Two Ethernet LAN ports
